• FrenchCreek’s PD11 Adjustable Barrel Mount Sleeve is designed for shoring, wall parapet applications where frequent setup over varying wall thickness is required.
• The mount is designed to provide fall protection to users in-line with the direction of the barrel.
• The PD11 can rotate 360° for rescue applications.
• The variable offset mast is equipped with FrenchCreek’s mechanical work-winch and rescue SRL
• The lightweight aluminum alloy design and quick-connect/release pins, allow for easy setup, dismantle, and transport.

PD11 Adjustable Barrell / Trench Box Base Davit System

• The Adjustable barrel / trench box mount is designed for bolt on installation to existing edges, walls and, other properly rated structures.
• Attaches to properly rated structures 3” to 24” thick
• 8pcs. 3/4” x 6” hex head set screws for securing to structure
• Zinc plated welded steel construction with PVC mast sleeve insert.
• 180° mast rotation.
• 9” tall sleeve PVC insert.
• PD11 Adjustable Barrell / Trench Box Base Complete Unit consists of Part numbers PD11, PD1, PD3, PD4, MW50G and R50G.
• (All 6 Parts of the complete unit are automatically selected upon ordering.)
• Powder-coated aluminum and plated alloy steel
• Davit meets OSHA 1926.502 and 1910.66 regulations
• Item weight: 150lbs
• Quickship Item
• Free Ground Shipping

Features:

• PD11 Complete System Includes: Part Number PD11, PD2, PD3, PD4, MW50G Winch, R50G rescue SRL
• PD11 Adjustable Barrel Mount – 3 to 24″ thick
• Rescue SRL: R50G 3-way rescue SRL
• Lifeline Length & Material: 50' Galvanized Steel
• Winch: MW50G Work Winch
• Hardware Material: Powder Coated Aluminum, Plated Alloy Steel
• Adjustability: 3″ to 24″ thick properly rated structures
• Installation: Temporary

Davit System Component Details:

PD1 - Davit Mast Assembly

• Telescoping adjustability from 12” to 30”
• Primary and secondary pulleys for multiple devices
• Attachment points for mechanical devices
• Swiveling design allows easy hole exit & rescue
• Lightweight powder coated aluminum & alloy steel
• Item weight 32.75 lbs.

PD11 - Adjustable Barrell / Trench Box Base

• PD11 Barrel Mount Davit Base attaches to properly rated structures 3” to 24” thick.
• Attaches to properly rated structures
• 3” to 24” thick.
• 8pcs
• 3/4” x 6” hex head set screws for securing to structure
• Zinc plated welded steel construction with PVC mast sleeve insert
• 180° mast rotation.
• 9” tall sleeve PVC insert.
• Item weight: 48 Lbs

PD3 - R50G Mounting Bracket

• Used to attach R50G Rescue SRL to PD1 Davit Mast Assembly.
• Attaches with locking pins.
• Material: plated alloy steel.
• Item weight: 7.2 lbs.

PD4 - MW50G Mounting Bracket

• Used to attach MW50G Work Winch to PD1 Davit Mast Assembly.
• Attaches with locking pins.
• Material: plated alloy steel.
• Item weight: 4.8 lbs.

MW50G - Material Work Winch

• Requires PD4 mounting bracket for Davit System (included)
• 50’ galvanized wire rope
• Friction braking system
• Stainless steel
• Rugged, steel frame drum
• Item weight: 35 lbs.

R50G - 3-Way Rescue SRL

• Requires PD3 mounting bracket for Davit System (Included)
• 50’ galvanized wire rope lifeline
• Dual internal inertia braking system
• Load indicating snaphook included
• Stainless steel
• Item weight: 25 lbs.
